| Shaft outer diameter | Ø6mm |
|---|---|
| Max. response frequency | 300kHz |
| Max. allowable revolution | 5000rpm |
| Starting torque | Max. 40gf.cm(max. 0.00392N.m) |
| Resolution | 3000P/R |
| Output phase | A, B, Z |
| Control output | Totem pole |
| Power supply | 12-24VDC  ±5%(ripple P-P: max. 5%) |
| Connection type | Radial cable type |
| Protection structure | IP50 |
| Environment_Ambient temperature | -10 to 70℃, storage: -25 to 85℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 90% RH |
| Accessories | Ø6mm coupling standard, Ø8mm coupling(sold separately) |
| Weight | Approx. 120g |
انکودر AUTONICS مدل E40S6-5000-3-T-24
- Shaft outer diameter : Ø6mm
- Max. response frequency : 300kHz
- Max. allowable revolution : 5000rpm
- Starting torque : Max. 40gf.cm(max. 0.00392N.m)
- Resolution : 3000P/R
- Control output : Totem pole
- Power supply : 12-24VDC ±5%(ripple P-P: max. 5%)
- Connection type : Radial cable type
- Protection structure : IP50
